FAR FHU05 Structural Air Riveter
Base Tool

Model Number FHU05   Part Number FHU05

FAR FHU05 | Air Rivet Tool

Our extensive range of Structural Air Riveters Genuine FAR Tooling Subject to Stock & Availability

Benefits
  • Lightweight, Fast Operation
  • Ideal For High Volume Production
  • 19.5mm Stroke
  • 22.555 N Traction Power
  • Capable Of Setting Huck Lock Bolt Fasteners
  • Capable Of Setting Structural Rivets
  • Base Tool Only " Nose Assembly Must Be Purchased Separately"
Please refer to the Details & Tech Spec tab below for more information.

Be the first to review this item

This product currently has limited stock

£489.00 ex. vat

£586.80 inc. vat

Buy Now

FAR FHU05 Structural Air Riveter | Base Tool





Features

The FAR FHU05 Structural Rivet Tool Is a Heavy Duty Tool, Which is capable of setting a variety and various types of sturctural rivets once being equipped with the relivent heads/nose assemblies. This then enables the tool to become capable of setting and installing the following: LockBolts ®, Pin & Collar ®,  Magna-Lok ®, Monobolt ® , Ultra-Grip ® , Avdelok ® , Magna-Grip ® Hucktainer ®, Max Lok ®, Structural ®, Orlock Rivets ®, Hemlock ®, Magna Bulb ®.

FAR FHU05 Structural Rivet Nut Tool To suit 4.8mm - 7.8mm Structural/ Pin & Collar Rivets

This FHU05 is a base tool a nose assembly must be fitted or purchased separately.

Benefits

  • Lightweight, Fast Operation
  • Ideal For High Volume Production
  • 19.5mm Stroke
  • 22.555 N Traction Power
  • Capable Of Setting Huck Lock Bolt Fasteners
  • Capable Of Setting Structural Rivets
  • Base Tool Only " Nose Assembly Must Be Purchased Separately"



Do you require a tool repair / service? Click Here!



Setting Capacity (Lock Bolts)

Lock Bolt TypeC6L
4.8mm
6.4mm

Lock Bolt TypeMagna Grip
4.8mm
6.4mm


What Is A Huck C6L ?





What Is A Huck Magna Grip ?





FAR FHU05 Structural Air Riveter | Base Tool

SpecificationFAR FHU05
Brand FAR
Model FHU05
Part Number FHU05
Type Structural Air Riveter
Setting Capacity 4.8mm - 7.8mm
Contents FAR FHU05 Air Riveter | Base Tool
Weight 2.65kg
Stroke 19.5mm
Traction Power 22.555 N at 6 BAR
Working Pressure  6 BAR
Air Consumption Per Cycle  10.9 Lt
Min Int Diam Of The Compressed Air Feeding Hose  8mm

Some Of The Sizes This Riveter Can Set:

  • Pin & Collar, Avdelok and similar -  4.8mm to 6.4mm
  • Magna-Grip, Maxlok and similar -  4.8mm to 6.4mm
  • Structural Orlock Rivets -  7.8mm
  • Hemlok, Magna Bulb -  6.4mm

Extra Optional Features

PCL, Schrader & CEJN Set Up's Available. (Please Choose)

We also have a Wide Range of Fasteners, Materials & Grip Ranges Available Click Here for more information.

Part Number Product Title Price
123927 123927
6.4mm Huck C6L Jaw Set FAR FHU05 Part
1/4"
Avdelok
£51.75 ex. vat Add to cart
710258' 710258
O Ring
FAR FHU05 Part
5-612
£1.05 ex. vat Add to cart
710350, 710350
O Ring
FAR FHU05 Part
2-109
£1.05 ex. vat Add to cart
710367, 710367
O Ring
FAR FHU05 Part
2-8
£1.05 ex. vat Add to cart
710402, 710402
Seeger Ring
FAR FHU05 Part
22
£1.05 ex. vat Add to cart
710528, 710528
O Ring
FAR FHU05 Part
008
£1.05 ex. vat Add to cart
710548 710548
Dampener
FAR FHU05 Part
£1.73 ex. vat Add to cart
710579 710579
O Ring
FAR FHU05 Part
2-113
£1.05 ex. vat Add to cart
710822, 710822
Valve Piston ll
FAR FHU05 Part
£3.82 ex. vat Add to cart
710824, 710824
Push Button
FAR FHU05 Part
£1.05 ex. vat Add to cart
710839' 710839
Oil Tank Plug
FAR FHU05 Part
£2.73 ex. vat Add to cart
710873. 710873
Balancer Hook
FAR FHU05 Part
£3.82 ex. vat Add to cart
710905, 710905
Seeger Ring
FAR FHU05 Part
£1.05 ex. vat Add to cart
710906' 710906
Hermetic Washer
FAR FHU05 Part
£1.64 ex. vat Add to cart
710909, 710909
Connector
FAR FHU05 Part
2023
£5.45 ex. vat Add to cart
710916, 710916
O Ring
FAR FHU05 Part
2-15
£1.05 ex. vat Add to cart
710918' 710918
O Ring
FAR FHU05 Part
2-5
£1.05 ex. vat Add to cart
710919' 710919
O Ring
FAR FHU05 Part
2-4
£1.05 ex. vat Add to cart
710922, 710922
O Ring
FAR FHU05 Part
Dowty
£1.05 ex. vat Add to cart
711092' 711092
Key
FAR FHU05 Part
£1.09 ex. vat Add to cart
711225. 711225
Cylinder Cover
FAR FHU05 Part
£16.26 ex. vat Add to cart
711252. 711252
Tube
FAR FHU05 Part
£3.37 ex. vat Add to cart
711253. 711253
Valve Piston l
FAR FHU05 Part
£6.36 ex. vat Add to cart
711258 711258
O Ring
FAR FHU05 Part
Washer Piston
£6.09 ex. vat Add to cart
711259. 711259
Cap
FAR FHU05 Part
£1.09 ex. vat Add to cart
711304, 711304
Silencer
FAR FHU05 Part
£11.00 ex. vat Add to cart
711305, 711305
Connector
FAR FHU05 Part
1631
£4.36 ex. vat Add to cart
711336. 711336
O Ring
FAR FHU05 Part
2-114
£1.05 ex. vat Add to cart
711337. 711337
O Ring
FAR FHU05 Part
2-21
£1.05 ex. vat Add to cart
711339. 711339
O Ring
FAR FHU05 Part
2-129
£1.64 ex. vat Add to cart
711340. 711340
O Ring
FAR FHU05 Part
2-343
£5.91 ex. vat Add to cart
711366 711366
Head Ring Nut
FAR FHU05 Part
£16.26 ex. vat Add to cart
711370. 711370
Output Connector
FAR FHU05 Part
£5.55 ex. vat Add to cart
711722, 711722
Balsele Seal Nei
FAR FHU05 Part
£10.81 ex. vat Add to cart
711821, 711821
Seeger Ring JV
FAR FHU05 Part
£1.05 ex. vat Add to cart
712117, 712117
Washer
FAR FHU05 Part
Washer Stopping Spring
£1.09 ex. vat Add to cart
712133, 712133
Rotating Connector
FAR FHU05 Part
Air
£6.37 ex. vat Add to cart
712162, 712162
Silencer Protector
FAR FHU05 Part
£1.37 ex. vat Add to cart
712268, 712268
Spring Guide Plug
FAR FHU05 Part
£4.36 ex. vat Add to cart
712282. 712282
Safety Washer
FAR FHU05 Part
£1.05 ex. vat Add to cart
712283 712283
Guard Deflector
FAR FHU05 Part
£2.18 ex. vat Add to cart
713247. 713247
Bush
FAR FHU05 Part
£3.00 ex. vat Add to cart
713258. 713258
Anti-Extrusion Ring
FAR FHU05 Part
£5.73 ex. vat Add to cart
713272. 713272
O Ring
FAR FHU05 Part
2-125
£1.09 ex. vat Add to cart
713273. 713273
O Ring
FAR FHU05 Part
17-5
£1.05 ex. vat Add to cart
713274. 713274
O Ring
FAR FHU05 Part
8-15
£1.05 ex. vat Add to cart
713275. 713275
O Ring
FAR FHU05 Part
2-12
£1.09 ex. vat Add to cart
713276. 713276
Balsele Seal Tse
FAR FHU05 Part
£9.72 ex. vat Add to cart
713278. 713278
O Ring
FAR FHU05 Part
2-122
£1.09 ex. vat Add to cart
713279 713279
Balsele Seal
FAR FHU05 Part
£9.72 ex. vat Add to cart
721387' 721387
Oil Container
FAR FHU05 Part
Priming Pump
FHU05
£11.77 ex. vat Add to cart
722036 722036
Trigger Assembly
FAR FHU05 Part
Long Valve Body Assembly
£22.69 ex. vat Add to cart
723264 723264
Cone Holding Kit
FAR FHU05 Part
Cone Holding Head Assy Assembly
£47.63 ex. vat Add to cart
740840, 740840
Valve Spacer Kit
FAR FHU05 Part
FHU05
£8.10 ex. vat Add to cart
